1-1/2" 38.1mm x .065" 1.65 mm Pines Dynacut

Stock #: 0106117

Equipped With

SPECIFICATIONS:
Maximum Tube Diameter: 1-1/2″ (38.1mm)
Minimum Tube Diameter: 1/8″ (3.175mm)
Maximum Wall Thickness: .065″ (1.65mm)
Maximum Cut Length: 60″ (Standard Tools)
Minimum Cut Length: 2-1/2″ (Standard Tools)
Production Rate, Gross: 6,200 Pcs. Per Hour

EQUIPPED WITH:
Run Out w/Target 2′ W x 6′ L x 5′ High
BIJUR Lube System
End Cropping

NOTE:
Rebuilt Controls, PLC
Motor Data: 5 HP, 220/440/640 – 1800 RPM w/VICKERS #PVB10 Pump

OVERALL DIMENSIONS: 4′ 6″ W x 6′ L x 4′ High
APPROXIMATE WEIGHT: 10,000 Lbs.

1-1/2" 38.1mm x .065" 1.65 mm Pines Dynacut

STOCK # 0106117

Specifications

View All Details
Machine Type
Other Cutting Tools
Manufacturer
PINES
Model
15
Year
1964
Condition
Good
Equipped With

SPECIFICATIONS:
Maximum Tube Diameter: 1-1/2″ (38.1mm)
Minimum Tube Diameter: 1/8″ (3.175mm)
Maximum Wall Thickness: .065″ (1.65mm)
Maximum Cut Length: 60″ (Standard Tools)
Minimum Cut Length: 2-1/2″ (Standard Tools)
Production Rate, Gross: 6,200 Pcs. Per Hour

EQUIPPED WITH:
Run Out w/Target 2′ W x 6′ L x 5′ High
BIJUR Lube System
End Cropping

NOTE:
Rebuilt Controls, PLC
Motor Data: 5 HP, 220/440/640 – 1800 RPM w/VICKERS #PVB10 Pump

OVERALL DIMENSIONS: 4′ 6″ W x 6′ L x 4′ High
APPROXIMATE WEIGHT: 10,000 Lbs.
