10' X 16GA ROTO-DIE MODEL 10 HYDRAULIC PRESS BRAKE. STOCK # 0134325.

Stock #: 0134325

Equipped With

STROKE LENGTH......................: 3"
STROKES PER MINUTE RANGE...........: 20 - 50
DIE SPACE..........................: 7-1/2"
DIE CLEARANCE......................: 2-1/8"
BENDING CAPACITY W/ 7/8" DIE.......: 10' X 16 GA
BENDING CAPACITY W/ 1/2" DIE.......: 10' X 20 GA
BENDING CAPACITY W/ ANGLE INSERT...: 6' X 10 GA
BED AND RAM PLATE THICKNESS........: 2-1/4"
BED AND RAM DEPTH..................: 25"
BED & RAM LENGTH...................: 123"
MOTOR HORSEPOWER...................: 7-1/2
MOTOR RPM..........................: 1755
OVERALL DIMENSIONS.................: 12'1" X 1'10" X 5'4"
APPROX. WEIGHT.....................: 5,700 LBS
