15" X 50" AMERICAN MACHINE TOOL GAP BED ENGINE LATHE. STOCK # 0103822

Stock #: 0103822

Equipped With

SERIAL.........................: 15588110821
MODEL..........................: TURNSMASTER 1550
SWING..........................: 15"
SWING OVER THE CROSS SLIDE.....: 8-1/2"
DISTANCE BETWEEN CENTERS.......: 50"
SPINDLE NOSE...................: D1-6 CAMLOCK
CHUCK SIZE.....................: 10"
SPINDLE SPEEDS.................: (16) 25-2000
SPINDLE BORE...................: 2-3/16"
INCH THREADING.................: (45) 2-72 TPI
METRIC THREADING...............: (39) 0.2 - 14MM
INCH FEEDS.....................: (15) 0.0015 - 0.040
METRIC FEEDS...................: (15) 0.04 - 1.00
D.P. FEEDS.....................: (21) 44 - 8
THREADS PER INCH...............: 1-1/4", 4 TPI
COMPOUND TRAVEL................: 4-1/4"
CROSS SLIDE TRAVEL.............: 8-1/8"
WIDTH OF BED...................: 11"
MOTOR..........................: 7.5"
STEADY REST....................: 7"
POWER REQUIREMENTS:
98" X 40" X 52"
3,000 LBS

15" X 50" AMERICAN MACHINE TOOL GAP BED ENGINE LATHE. STOCK # 0103822

STOCK # 0103822

SERIAL.........................: 15588110821
MODEL..........................: TURNSMASTER 1550
SWING..........................: 15"
SWING OVER THE CROSS SLIDE.....: 8-1/2"
DISTANCE BETWEEN CENTERS.......: 50"
SPINDLE NOSE...................: D1-6 CAMLOCK
CHUCK SIZE.....................: 10"
SPINDLE SPEEDS.................: (16) 25-2000
SPINDLE BORE...................: 2-3/16"
INCH THREADING.................: (45) 2-72 TPI
METRIC THREADING...............: (39) 0.2 - 14MM
INCH FEEDS.....................: (15) 0.0015 - 0.040
METRIC FEEDS...................: (15) 0.04 - 1.00
D.P. FEEDS.....................: (21) 44 - 8
THREADS PER INCH...............: 1-1/4", 4 TPI
COMPOUND TRAVEL................: 4-1/4"
CROSS SLIDE TRAVEL.............: 8-1/8"
WIDTH OF BED...................: 11"
MOTOR..........................: 7.5"
STEADY REST....................: 7"
POWER REQUIREMENTS:
98" X 40" X 52"
3,000 LBS

Specifications

Machine Type
Lathes, Engine
Manufacturer
American
Model
TURMASTER 1550
Year
N/A
Condition
Used
