15" x 54" LEBLOND MAKINO REGAL SERVO SHIFT LATHE. STOCK # 0954020

Stock #: 0954020

Equipped With

Year of Mfg: 1990



Swing over bed and Carriage Ways:.......... 15 1/2"

Swing over cross Slide:.................... 9 1/2"

Distance between Centers:.................. 54"

Spindle Speeds:............................ 45 -1800

Spindle Thru Hole:......................... 2.25"

Spindle Taper:............................. Morse Taper # 4

Bed Width:................................. 12 3/16"

Feed Range:................................ .0018 IPR to .104 IPR

Thread Changes:............................ 48

Threads:................................... 2 to 112 TPI

Tailstock Spindle Diameter:................ 1 15/16"

Motor:..................................... 7 1/2 HP, 1800 RPM



Weight 3260 lbs.

Floor Space 104.25 x 40"



Equipped With:



Tailstock

Coolant Tank & Pump

15" x 54" LEBLOND MAKINO REGAL SERVO SHIFT LATHE. STOCK # 0954020

STOCK # 0954020

Year of Mfg: 1990



Swing over bed and Carriage Ways:.......... 15 1/2"

Swing over cross Slide:.................... 9 1/2"

Distance between Centers:.................. 54"

Spindle Speeds:............................ 45 -1800

Spindle Thru Hole:......................... 2.25"

Spindle Taper:............................. Morse Taper # 4

Bed Width:................................. 12 3/16"

Feed Range:................................ .0018 IPR to .104 IPR

Thread Changes:............................ 48

Threads:................................... 2 to 112 TPI

Tailstock Spindle Diameter:................ 1 15/16"

Motor:..................................... 7 1/2 HP, 1800 RPM



Weight 3260 lbs.

Floor Space 104.25 x 40"



Equipped With:



Tailstock

Coolant Tank & Pump

Specifications

Machine Type
Lathes, Engine
Manufacturer
LEBLOND MAKINO
Model
Regal
Year
N/A
Condition
Very Good
