150 TON MINSTER S2-150-96-42 STRAIGHT SIDE DOUBLE CRANK PRESS. STOCK # 1158022

Stock #: 1158022

Equipped With

SERIAL........................: 13542
MODEL.........................: S2-150-96-42
TONNAGE.......................: 150
STROKE........................: 15"
SHUT-HEIGHT...................: 24"
ADJUSTMENT....................: 10"
SPM...........................: 18
BED SIZE......................: 96" L-R X 42" F-B
RAM SIZE......................: 96" L-R X 36" F-B
T SLOTTED RAM AND BOLSTER.....: YES
BOLSTER THICKNESS.............: 5-1/2"
PASSLINE HEIGHT...............: 33-1/2"
WINDOW........................: 16" X 16"
CUSHION CAPCITY...............: 32 TONS
STROKE OF CUSHION.............: 4"
MOTOR.........................: 20 HP
RPM...........................: 1200
