200 TON BLISS C-200 OBI PRESS. STOCK # 0886825

Stock #: 0886525

Equipped With

SERIAL...............................: H-47466
MODEL................................: C-200
TONNAGE..............................: 200
STROKE...............................: 8"
SHUT-HEIGHT..........................: 24"
ADJUSTMENT...........................: 4.5"
SPM..................................: 60, INCH, SINGLE, CONTINUOUS
BED SIZE.............................: 58" L-R X 34" F-B
RAM SIZE.............................: 36" L-R X 28" F-B
BOLSTER THICKNESS....................: 4.5"
PALM AND FOOT CONTROLS...............: YES
AIR COUNTERBALANCE...................: YES
BRONZE REPLACEABLE GIBS
TRABON LUBE SYSTEM
FOOT ISOLATION PADS
30 HP MOTOR
230/460 VOLT
AMPS: 40/20

200 TON BLISS C-200 OBI PRESS. STOCK # 0886825

Download Images

SERIAL...............................: H-47466

MODEL................................: C-200

TONNAGE..............................: 200

STROKE...............................: 8"

SHUT-HEIGHT..........................: 24"

ADJUSTMENT...........................: 4.5"

SPM..................................: 60, INCH, SINGLE, CONTINUOUS

BED SIZE.............................: 58" L-R X 34" F-B

RAM SIZE.............................: 36" L-R X 28" F-B

BOLSTER THICKNESS....................: 4.5"

PALM AND FOOT CONTROLS...............: YES
AIR COUNTERBALANCE...................: YES
BRONZE REPLACEABLE GIBS

TRABON LUBE SYSTEM

FOOT ISOLATION PADS
30 HP MOTOR
230/460 VOLT
AMPS: 40/20

Specifications

Machine Type

Presses, O.B.I, Back Geared, Single Crank

Manufacturer

BLISS

Model

C-200

Year

N/A

Condition

Used
