250 TON PRO-ECO 4 POST CUTOFF PRESS: STOCK # 0314023

Stock #: 0314023

Equipped With

SERIAL .................... 3904-18-82
MODEL ..................... MCP-250-4-36-76-200
CAPACITY .................. 250 TON
PRESS APPLICATION ......... #1 PREPIERCING UNIT
STROKE .................... 4"
SHUT HEIGHT ............... 13"
SHEIGHT HEIGHT ADJUSTMENT . 10" VIA DRIVEN WORMGEAR ARRANGEMENT
DISTANCE BETWEEN POSTS .... 37" X 79"
DIE SPACE ................. 36" X 76"
CRANK SPEED ............... 200 RPM
MAX CUTS PER MIN .......... 20
CLUTCH & BRAKE ............ WICHITA
LUBE SYSTEM ............... AUTO GREASE SYSTEM FROM PRESS TIMER
PIT DEPTH ................. 53"
AC MOTOR .................. 60HP/480/3/60
