2,500 LB ARONSON SKYHOOK 360 DEGREE TILT/ROTATE WELDING POSITIONER. STOCK # 1273523.

Stock #: 1273523

Equipped With

MACHINE DESCRIPTION:
The Aronson "SKYHOOK" is Designed to give you Full 360° of Tilt along with 360° of Rotation. This is accomplished by Mounting a Turn Table onto a Horizontal Beam and then Mounting the Horizontal Beam onto a Headstock. The Beam is Mounted 24" Below the Tilt Axis of the Headstock and the Turn Table Center is 30" From the Headstock. The Turn Table is 38" in Diameter and uses Pre-loaded Slew-ring roller bearings which provides an 18-1/2" Diameter Thru-Hole in the Table. Both Axes are equipped with Getty's Servo Motors and Feedback Encoders.

EQUIPPED WITH:
38" Table with (4) 3/4" Radial T-Slots, 18.5" Thru-Hole, Getty's Servo Motors and Encoders, Automatic Backlash Control, Auxiliary Brake on Input Shaft, Zero Pin and Visual Zero Indicator, NEMA Dust Tight Electronics.





Table Diameter
38"


Hole Thru Center of Table
18.5"


Max Swing
60"


Table Weight Load Capacity
2,500 LBS


Table Weight Load Capacity 48" Above Table
2,500 LBS


Range of Work Rotation Speeds
(+/- 10% Allowable Inf Var)
0 to 2 RPM


Rotation Torque
7,500 LB/IN


Tilt Speed
0 to 2 RPM


Tilt Torque
60,000 LB/IN


Floor to Table Top
36"


Electrics
440/3/60


Approximate Dimensions
92" x 92"


Approximate Height
88"


Approximate Weight
7,500 LBS
