4.1" Sacem Herkules MNU-106 CNC Horizontal Boring Mill

Stock #: 1500319

Equipped With

SPECIFICATIONS:

4.1Inch SACEM TABLE TYPE HORIZONTAL BORING MILL
MODEL: MNU-105
S/N: 90015
NEW: 1986
SPECIFICATIONS: SPINDLE DIAMETER....................... 4.1Inch
SPINDLE TAPER.......................... #50 TAPER
SPINDLE SPEEDS (20 SPEEDS)............. 16 TO 1,250 RPM
FEEDS (FOR X,Y,Z & W AIS) 27 FEEDS..... 0.0008 TO .333 IPR RAPID
FEEDS............................ 138 IPM HEADSTOCK
VERTICAL TRAVEL (Y-AXIS)..... 39-3/8Inch
SPINDLE HORIZONTAL TRAVEL (Z-AXIS)...... 23-5/8Inch
TABLE CROSS TRAVEL (X-AXIS)............ 55-1/8Inch
TABLE LONGITUDINAL TRAVEL (W-AXIS)..... 42-3/8Inch
DIMENSIONS OF BUILT IN ROTARY TABLE.... 31-1/2Inch X 39-3/8Inch TABLE
LOAD CAPACITY.................... 4,400 LBS MAIN
MOTOR............................. 12 HP
EQUIPPED WITH: * 50 TAPER POWER DRAW BAR * HARD WAYS ALL AXES *
INCH/METRIC THREADING



4.1" Sacem Herkules MNU-106 CNC Horizontal Boring Mill

STOCK # 1500319

Specifications

View All Details
Machine Type
Boring Mills, Horizontal, Floor Type
Manufacturer
SACEM
Model
MNU-105
Year
1986
Condition
Used
Equipped With
SPECIFICATIONS:

4.1Inch SACEM TABLE TYPE HORIZONTAL BORING MILL
MODEL: MNU-105
S/N: 90015
NEW: 1986
SPECIFICATIONS: SPINDLE DIAMETER....................... 4.1Inch
SPINDLE TAPER.......................... #50 TAPER
SPINDLE SPEEDS (20 SPEEDS)............. 16 TO 1,250 RPM
FEEDS (FOR X,Y,Z & W AIS) 27 FEEDS..... 0.0008 TO .333 IPR RAPID
FEEDS............................ 138 IPM HEADSTOCK
VERTICAL TRAVEL (Y-AXIS)..... 39-3/8Inch
SPINDLE HORIZONTAL TRAVEL (Z-AXIS)...... 23-5/8Inch
TABLE CROSS TRAVEL (X-AXIS)............ 55-1/8Inch
TABLE LONGITUDINAL TRAVEL (W-AXIS)..... 42-3/8Inch
DIMENSIONS OF BUILT IN ROTARY TABLE.... 31-1/2Inch X 39-3/8Inch TABLE
LOAD CAPACITY.................... 4,400 LBS MAIN
MOTOR............................. 12 HP
EQUIPPED WITH: * 50 TAPER POWER DRAW BAR * HARD WAYS ALL AXES *
INCH/METRIC THREADING
