42" SPRINGFIELD 42ER UNIVERSAL ID/OD VERTICAL GRINDER. STOCK # 1273623

Stock #: 1273623

Equipped With

MODEL.............................: 42E-RAIL
WORK TABLE DIAMETER...............: 42"
MAXIMUM SWING INSIDE GUARDS.......: 48"
NOMINAL HOLE ABILITY..............: 18"
MAX HEAD STROKE...................: 36"
DISTANCE UNDER RAIL...............: 25-1/2" WITH RAIL DOWN
DISTANCE UNDER RAIL...............: 49-1/2" WITH RAIL UP
HEAD ANGLE SETTING................: 45 DEG
CHUCK SPEED RANGE.................: 6-120 RPM
HEAD STROKE,FEED RATE.............: 0-80 IPM
CROSS FEED RATE,RANGE(IPD)........: .0002 - .003
TARRY PERIOD......................: 0 - 14 SECONDS
GRINDING WHEEL HP.................: 10
MAX SPINDLE SPEED.................: 4,200 RPM
RAIL TRAVEL.......................: 24"
