MAZAK CNC VERTICAL MACHINING CENTER

Stock #: 0305320

Equipped With

Machine Specifications:

Travels:
X-Axis: 44.10″
Y-Axis: 20.08″
Z-Axis: 20.08″

Spindle Nose to Table (Min.- Max.): 4.3″ – 24.4″
Spindle Center to Column: 22.1″

Table:
Length: 57.4″
Width: 20.2″

Spindle:
Taper Size: No. 40
Speed Range: 0 – 7,000 RPM
Spindle Power: 15/10 JP AC

 Feed rates:
Rapid Traverse Rate X & Y : 787ipm
Rapid Traverse Rate Z : 590ipm

Automatic Tool Changer:
Capacity: 24
Max Tool Weight: 17.6 lbs
Max Tool Length: 13.78″
Max Tool Dia: 4.3″

General:
Air Required: 70 psi, 5 scfm
Power: 220v / 66FLA / 3-Phase
Overall Dimensions: 118″ (163″) x 102″ x 106″ High
Weight: 12,000 lbs

MAZAK CNC VERTICAL MACHINING CENTER

STOCK # 0305320

Specifications

View All Details
Machine Type
Machining Centers, Vertical
Manufacturer
MAZAK
Model
VTC 20B
Year
N/A
Condition
Not specified
Equipped With

Machine Specifications:

Travels:
X-Axis: 44.10″
Y-Axis: 20.08″
Z-Axis: 20.08″

Spindle Nose to Table (Min.- Max.): 4.3″ – 24.4″
Spindle Center to Column: 22.1″

Table:
Length: 57.4″
Width: 20.2″

Spindle:
Taper Size: No. 40
Speed Range: 0 – 7,000 RPM
Spindle Power: 15/10 JP AC

 Feed rates:
Rapid Traverse Rate X & Y : 787ipm
Rapid Traverse Rate Z : 590ipm

Automatic Tool Changer:
Capacity: 24
Max Tool Weight: 17.6 lbs
Max Tool Length: 13.78″
Max Tool Dia: 4.3″

General:
Air Required: 70 psi, 5 scfm
Power: 220v / 66FLA / 3-Phase
Overall Dimensions: 118″ (163″) x 102″ x 106″ High
Weight: 12,000 lbs
