WARNER & SWASEY 2A SADDLE TYPE TURRET LATHE. STOCK # 0848220

Stock #: 0848220

Equipped With

SERIAL ........................... 1862778
MODEL ............................ #2A (M-3470) SQUARE HEAD
SWING OVER BED ................... 20"
SWING OVER CARRIAGE .............. 16-3/4"
MAX DISTANCE TURRET TO SPINDLE ... 40"
SPINDLE SPEEDS ................... (32) 16 - 1117 RPM
CROSS FEEDS ...................... (16) .002 TO .073 IPR
LONGITUDINAL AND TURRET FEEDS .... (16) .004 TO .149 IPR
DIAMETER OF SPINDLE HOLE ......... 4-3/4"
TURRET POSITIONS ................. 6
COOLANT .......................... YES


WARNER & SWASEY 2A SADDLE TYPE TURRET LATHE. STOCK # 0848220

STOCK # 0848220

Specifications

View All Details
Machine Type
Lathes, Turret
Manufacturer
WARNER & SWASEY
Model
2A
Year
N/A
Condition
Very Good
Equipped With
SERIAL ........................... 1862778
MODEL ............................ #2A (M-3470) SQUARE HEAD
SWING OVER BED ................... 20"
SWING OVER CARRIAGE .............. 16-3/4"
MAX DISTANCE TURRET TO SPINDLE ... 40"
SPINDLE SPEEDS ................... (32) 16 - 1117 RPM
CROSS FEEDS ...................... (16) .002 TO .073 IPR
LONGITUDINAL AND TURRET FEEDS .... (16) .004 TO .149 IPR
DIAMETER OF SPINDLE HOLE ......... 4-3/4"
TURRET POSITIONS ................. 6
COOLANT .......................... YES
